CE Ex Ib IIC T4 Gb Single Gas Detector Explosion Proof Portabel For Factory / Home

Name: CE Ex Ib IIC T4 Gb Single Gas Detector Explosion Proof Portabel For Factory Home
Brand: Eyesky
Price: 1 USD

Brand Name : Eyesky

Model Number : ES20B

Certification : CE,ROUSH

Place of Origin : CHINA

MOQ : 1

Payment Terms : L/C, Western Union, T/T, MoneyGram

Delivery Time : 2~3 days

Accuracy : ±3%FS

Working pressure : 86kPa~106kPa

Continuous working time : ≥12 hours

Respond time : T90 ≤30 sec

Operation method : Key operation

Dimension : 135x65x35mm(LxWxH)

Contact Now

The circuit adopts 4-layer wiring , which is stronger to weak signal and anti-interference; The independent high precision imported AD chip is equipped with the signal processing algorithm with no vision, and the measurement result is more accurate and stable;

Name	Descripition
Product name :	ES10B fixed gas detector
Detection principle :	Capacity combustion,infrared detect,eletrochemical,PID,heat conductance;
Display mode :	LCD screen display ;
Display unit :	%VOL,%LEL,ppm,mg/m3 ;
Back light :	White ,yellow,red three color back light ,Normal, fault, alarm indication;
Alarm mode :	Sound and light alarm, relay output alarm
Precision :	≤±3%FS;
Preheat time :	≤60s;
Output signal :	It can transmit up to 2000 meters (single core 1mm2 shielded cable) according to the actual environmental requirements of the site
	1 path 4~20mA current signal output
	1path RS-485 signal output,standard ModBus RTU(optional function);
	1path 200~1000Hzfrequency signal output(Output pin and sound and light alarm multiplexing, optional function);
	Can chose 0~5V or 0~10V output (optional function);
Relay :	Two sets of OMRON relays;Passive contact capacity: 220VAC 0.5a or 24VDC 1A;
Material of body :	Shell :die-cast aluminium ;
	Gas chamber :alumina carbide
Installation mode :	Wall mounted pipe integrated;
Working temperature :	-40℃~+70℃(combustible);-20℃~+50℃(toxic);
Working humidity :	10%~95%RH(no condensation);
Working voltage :	24VDC(normal operation voltage range:9~30VDC);
Power dissipation :	<2.5W(combustible gas );<1.5W(toxic gas );
Working pressure :	86~106KPa;
Dimension :	180mm140mm92mm(LWH);
Weight :	About 1.6Kg ;
Explosion proof grade :	Exd II CT6;
Protection grade :	IP66;
Operation standard :	GB15322.1-2003,GB3836.1-2010,GB3836.2-2010,GB3836.4-2010;
